Mini Mono
The Mini Mono is our most compact Monobloc machine, designed from the ground up to suit your product, fully automatic filling & capping with multiple stations available.
This machine is brilliant for those looking for a full production line, but with limited space like for instance a clean room or laboratory..
Compact Mono Bloc Filling & Capping Machine.
The Mini Mono was designed specifically for situations where space is at a premium or where access is limited. That why the machines foot print is so compact for the amount of features that can be optioned.
This makes it an ideal machine for industries such as life science or pharmaceutical but can work in any environment, even comes in an ATEX variant for those challenging productions spaces.
The Mini Mono can also be fitted with many stations, such as powder filling, liquid filling, level detection, twin head cappers, cap presence detection and much more. Making this compact packaging machinery extremely versatile and capable of dealing with complex products.
If your looking for a more capable solution than standard filling and capping machines, then the Mini Mono is your perfect solution, but if you’re not sure, we are here to help, we can even design full turnkey production solutions taking the hassle out of organising multiple bits of machinery.
All of our machines come with a comprehensive 12 month warrant on parts & labour.
40 Bottles Per Minute
Up to 40 mm Diameter
Up to 250mm Height
Up to 66mm Diameter
Why the Mini Mono is essential for your growing business?
Flexible Leasing Deals Available
Investing in new machinery doesn’t have to mean a large upfront cost. With our tailored leasing solutions, you can spread the cost of your equipment over manageable monthly payments—making it easier to preserve capital, manage cash flow, and access the latest technology without delay.
Why Choose Leasing?
- Preserve Working Capital: Keep your cash reserves free for other business needs while still acquiring the machinery you need today.
- Fixed Monthly Payments: Enjoy predictable costs with fixed payments throughout the term, simplifying budgeting and forecasting.
- Fast Access to Equipment: Leasing allows you to move quickly, so you can respond to market demand without long capital approval processes.
Tax-Efficient Financing
Leasing can also offer significant tax advantages for UK businesses. In many cases, lease payments are 100% tax deductible against profits, reducing your overall tax liability. This makes leasing not only a smart operational choice but also a financially efficient one.
Technical Specifications & Options
Cap & Bottle Dimensions
| Cap Diameter: | *Ø40mm |
| Bottle Height: | Up to 250mm |
| Bottle Width: | Up to 64mm |
| Cap & Bottle Shape: | Any shape considered. |
Machine Dimensions
| Height: | 1935mm |
| Width: | 894mm |
| Depth: | 704mm |
| Base Weight: | 230kgs * |
| Working Height: | 900mm |
| Construction: | Aluminium extrusion with stainless steel covers and polycarbonate guarding. |
Electrical Supply
| Supply: | 230v Single phase, supplied via BS 1363 13A Plug |
| Consumption: | 2.2kW |
| Controls: | Supplied with Schneider PLC & HMI. |
Pneumatic Supply
| Supply: | 8mm Push fit |
| Supply Pressure: | 5 Bar |
| Consumption: | Notionally 20 Litre/Min |
Machine Options
Infeed Rotary Table
Allows automatic bottle feeding into the starwheel. Simply place your bottles on the rotary table and watch the machine go!
Outfeed Rotary Table
Don’t need a labeller? Just want a simple outfeed? Then we have a range of outfeed table sizes and types available for your new production line.
Labellers
No bottle is complete without a label, so why not option a labeller? We have a great range on offer to suit your needs.
Conveyors
Need to get your product to another part of production? No problem we do conveyors too!
We can even integrate the controls into the mini mono’s HMI.
Peristaltic Pump
Looking to keep control of contamination and reduce cleaning time? Its on of a number of benefits to using a peristaltic pump. Powered by a servo motor for brilliant fill accuracy.
Gear Pump
Bigger fills? Look no further, our gear pumps will fill your products in no time. Driven by a servo motor to ensure accuracy on any fill volume.
Shut Off Nozzle
Don’t want your product dripping? Our compact shut off nozzle is the solution. With a range of nozzle & infeed sizes. This nozzle stainless steel is a perfect companion.
Diving Nozzle
Got a product that can splash? You need a diving nozzle, whether is top down fill or bottom up we have it all covered.
Crimp Head
Lets crimp! Some caps require crimping rather than being screwed. Perfume bottles is a great example. Swap out the torque head for a crimp head.
ROPP Head
The Mini Mono is so flexible it can even fit an Roll-On Pilfer-Proof head in for those bottles that need it. Just like small wine bottles.
Torque Transducer
Need a calibrated torque reading? We regularly integrate torque transducers into our torque head. Great for pharmaceutical industry.
Hopper Elevator
Who’s wants to run out of caps feeding there machine. Not us, that why we supply hopper elevators for additional capacity on your automatic line.
Layouts & Diagrams
A Typical Automatic Mini Mono Layout.
Consisting of the base automatic Mini Mono Multi Head Capper, combination filler with both peristaltic and gear pump driven with servo motors for incredible accuracy. Together with central conveyor, twin cap bowl feeders and filler hopper. A complete turnkey solution featuring the Mini Mono Capper. The operators would simply load the caps into the twin bowl feeders, prime the filling station, and load the empty bottles onto the conveyor and then monitor the machine as it does all the rest. Watch as the bottles enter from the left, get filled and the levels checked, the caps then placed on and then capped with our capping head. Finally the caps are checked and the finished product moved back onto the conveyor, exiting the machine.
At Cap Coder we know it’s all down to the detail, that’s why we provide machine layouts at point of quotation if you require, free of charge. These help you understand the machine dimensions and potential ancillary equipment location.
Need a site visit? We can arrange one of our experienced sales engineers to meet you on site to discuss your vision and requirements.
